WR-5887: AC1200 Wireless Router

Maximizes your Internet Experience
11ac is up to 3x faster than 11n technology.

Superior Coverage
11ac with simultaneous dual band technology reaches farther and improves performance compared to 11n.

Ultra Fast Wired Connectivity
Gigabit ports-10x faster than standard ports.

Fully Compatible with 11n Devices
11ac is backward compatible with older 11a/b/g/n technologies.

• Complies with IEEE 802.11a/b/g/n standards and IEEE 802.11ac draft
• Supports 2.4GHz and 5GHz wireless network connections simultaneously
• Supports 2T2R MIMO technology in 5GHz frequency and 2T2R MIMO technology in 2.4GHz frequency, significantly enhancing the performance and coverage range
• Supports 64/128-bit WEP, WPA and WPA2 for security and also IEEE 802.1x authentication
• High speed transmit and receive PHY rate – up to 867Mbps while operating in IEEE 802.11ac (5GHz, 80MHz) mode and up to 300Mbps while operating in IEEE 802.11a/n (5GHz, 40MHz) or IEEE 802.11b/g/n (2.4GHz) mode
• Supports WPS function for easy wireless association

Specifications

• SOC+RF: Realtek RTL8197D (CPU) + RTL8192CE (2.4G) + RTL8812AR (5G)
• Gigabit Switch: Realtek RTL8367R-VB
• Flash: 4MB SPI Flash
• RAM: 64MB DDR2 RAM
• WAN Port: 10/100/1000M (Auto-MDI/MDI-X) UTP Port x 1
• LAN Ports: 10/100/1000M (Auto-MDI/MDI-X) UTP Port x 4
• MIMO Technology: 5GHz: 2T2R MIMO, 2.4GHz: 2T2R MIMO
• Antenna: 3dBi Dual Band Fixed Dipole Antenna x 2
• Temperature : Operating: 0~40℃, Storage: -20~60℃
• Humidity: Operating: 10~90% (Non-Condensing)
• Storage: Max.95% (NonCondensing) Certification: CE / FCC

0utput Power:

2.4GHz ．

• 11b(11M): 16±1.5 dBm ．
• 11g(54M): 14±1.5 dBm ．
• 11n(20MHz, MCS7): 13±1.5 dBm ．
• 11n(40MHz, MCS7): 13±1.5 dBm

5GHz ．

• 11a(54M): 12±1.5 dBm ．
• 11n(20MHz, MCS7): 12±1.5 dBm ．
• 11n(40MHz, MCS7): 12±1.5 dBm ．
• 11ac(80MHz, VHTMCS9): 10±1.5 dBm

Receive Sensitivity:

2.4GHz ．

• 11b(11M): -84±2dBm ．
• 11g(54M): -70±2dBm ．
• 11n(20MHz, MCS7):-65±2dBm ．
• 11n(40MHz, MCS7):-63±2dBm

5GHz ．

• 11a(54M): -70±2dBm ．
• 11n(20MHz, MCS7): -68±2dBm ．
• 11n(40MHz, MCS7): -64±2dBm ．
• 11ac(80MHz, VHTMCS9): -54±2dBm

Power:

• 5V / 2A Switch Power Adapter

Dimension:

• 32(H) x 180(W) x 118(D) mm
