Features
- Interoperates with FTTx Deployments:
The PRT-6302 offers an ultra-fast 2.5 Gigabit Ethernet port for Gig+ speeds over its WAN connection. - Premium Performance for Video Streaming:
WiFi 6 (11ax) provides superior performance and coverage. - Connect More Devices Simultaneously:
WiFi 6 is ideal for simultaneously running multiple high-bandwidth devices. - TR-069 Remote Management for Reduced Truck Rolls:
Easily setup, manage, troubleshoot and control the CPE remotely.
Resources
Two page data sheet with product pictures and specifications.
Specifications
Hardware
- 4 x GbE RJ-45 LAN ports (10/100/1000 Base-T auto-sense)
- 1 x 2.5GbE RJ-45 WAN port (10/100/1000/2500 NBase-T)
- 1 x Reset Button
- 2 x WPS & WiFi On/Off button (2.4G and 5G)
- 4 x WiFi Antennas (4 dual band antenna)
- 1 x Power switch
- 1 x USB 3.0 Host
WLAN
- Up to AX6000Mbps PHY Rate
- Up to 1W Ultra High TX Power
- IEEE 802.11ax, 2.4GHz, 4T4R, backward compatible with 802.11n/g/b
- IEEE 802.11ax, 5GHz, 4T4R, backward compatible with 802.11ac/n/a
- WPA/WPA2/WPA3-PSK with TKIP & AES security type
- Multiple SSID
- MAC address filtering
802.1x radius supported - Supports entire 5GHz band including Dynamic Frequency Selection (DFS) channels
- Supports band steering
- Supports beamforming
Gigabit LAN
- 10/100/1000 Base T, IEEE 802.3, IEEE 802.3u IEEE 802.3ab
- Support MDI/MDIX
2.5Gigabit LAN
- IEEE 802.3bz
- 2.5G BASE-T, auto-sense
- Support MDI/MDX
Networking Protocols
- MAP-T and MAP-E support
- RFC 1483/2684 VC-MUX, LLC/SMAP encapsulations for bridged or routed packet
- IPoE, PPPoE, Bridge, IPoA, PPPoA
- PPPoE pass-through, Multiple PPPoE sessions on single WAN interface
PPPoE Filtering of non-PPPoE packets between WAN and LAN - Transparent bridging between all LAN and WAN interfaces
- 802.1p/802.1q VLAN Support
- Spanning Tree Algorithm
- IGMP Proxy V1/V2/V3, IGMP Snooping V1/V2/V3, Fast leave
- Static route, RIP v1/v2, ARP, RARP, SNTP
- DHCP Server/Client/Relay
- DNS Proxy/Relay, Dynamic DNS
- Internet Printing Protocol
- UPnP
- IPv6 subset
Management
- TR-069/TR-181/TR-104/TR-111/TR-143, SNMP, Telnet, Web-based management, Configuration backup and restoration
- Fine Point’s TR-069 enhanced functionality is available on this model with a firmware upgrade
- Software upgrade via HTTP, HTTPS, TFTP or FTP
Firewall/Filtering
- Stateful Packet Inspection Firewall
- Stateless Packet Filter
- Parental Control
- URI/URL Filtering
- Denial of Service (DOS): ARP attacks, Ping attacks, Ping of Death, LAND,SYNC, Smurf, Unreachable, Teardrop
- Port Scan Detection and Protection
- TCP/IP/Port/interface filtering rules Support both incoming and outgoing filtering
NAT/PAT
- Supports One to One, Many to One, Many to Many (Overload), Many to Many (No Overload) NAT
- NAT Loopback
- Port Triggering
- Port Forwarding (Virtual Server)
- Symmetric Port-Overloading NAT, Full-Cone NAT
- DMZ Host
- VPN Pass Through (PPTP, L2TP, IPSec)
USB
- File Sharing (DLNA & Samba)
- Print Server
Environment
- Operating temperature: 32~104°F (0~40°C)
- Relative humidity: 5~95% (non-condensing)
Note: Specifications are subject to change without notice.
