PG-9182 POE – 2000Mbps G.hn Powerline Ethernet Adapter with PoE

G.hn Wave 2 Powerline adapters can often pair faster by plugging a PG-9182PT into an outlet, and then plugging the second Wave 2 adapter into the PG-9182PT’s pass-through outlet. (Sold in kits and separately.)

Note: A minimum of 2 adapters are required to make a connection.

• G.hn is the Latest Standard in Powerline
  • G.hn continues to improve and develop while older technologies have been abandoned by developers.
• Now Available with PoE+
  • The PG-9182PoE has a flexible PoE configuration for a shared 30W budget
• 2 PoE-Capable Ethernet Ports
  • Connect up to 2 devices into your new G.hn Wave 2 Powerline Adapter.
• Easily Expand Your Network
  • Two adapters are required to make a connection. Connect up to 16 per network!

Specifications

Interface

• RJ-45 X 2
  • Flexible PoE configuration of 802.3af x 2 or 802.3at x1
• Power plug
• LED Indicators: Power, Connection, Security
  • LANx2, PoEx2
• Buttons: G.hn Pairing, Reset

Ethernet

• Standard IEEE 802.3
• 10/100/1000Mbps BaseT auto-sense
• Auto rate and duplex Negotiation MDI/MDX Support

G.hn (PLC)

• ITU-T G.9960 & G.9961 compliant
• G.hn 100MHz MIMO
• Up to 2000Mbps PHY rate
• NDIM support

Modulations

• OFDM
• FEC
• Flexible Frequency Configuration

Management

• HTTP Web-based
• TR-069

Security

• AES 128 bits encryption ensures total data security

Networking Protocols

• 802.1D Ethernet Bridge
• 802.1Q VLAN
• Quality of Service (QoS)
• IGMP (IPv4) Snooping & MLD (IPv6) Snooping

AC Power

• 100-240 VAC 50Hz/60Hz

Environment Condition

• Operating temperature: 32°F ~ 104°F (0°C ~ 40°C)
• Relative humidity: 8 ~ 95% (non-condensing)
• Designed for indoor use only

Dimensions

• 5.75in (H) x 2.84in (W) x 1.53in (D, without plug), 2.36in (D, with plug)
• 146mm (H) x 72mm (W) x 39mm (D, without plug), 60mm (D, with plug)

Certifications

• FCC
• cUL
• CE
• ITU-T G.hn Standard

Note: Specifications are subject to change without notice.
