Key Benefits
Note: A minimum of 2 adapters are required to make a connection.Features
- The PG-9182DC eliminates the need for the gateway to connect to both its power adapter and a separate G.hn Powerline adapter when creating a G.hn network. It does both!
- Blazing fast G.hn Wave 2 chipset speeds up to 2Gbps PHY rate over the Powerline connection deliver up to 1Gbps through the Ethernet port.
- Two adapters are required to make a connection. Connect up to 16 per network.
Resources
Product Sheet
Two page data sheet with product pictures and specifications.
Specifications
-
Interface
- RJ-45 X 1
- DC Output x 1 for 12VDC Output
- AC Power Jack x 1 for AC Power Cord
- LED Indicators: Power, Connection, Security, LAN
- Buttons: G.hn Pairing, Reset
Ethernet
- Standard IEEE 802.3
- 10/100/1000Mbps BaseT Auto-Sense
- Auto Rate and Duplex Negotiation
- MDI/MDX Support
G.hn (PLC)
- ITU-T G.9960 & G.9961 Compliant
- G.hn 100MHz MIMO
- Up to 2000Mbps PHY rate
- NDIM Support
Modulations
- OFDM
- FEC
- Flexible Frequency Configuration
Management
- HTTP Web-Based
- TR-069
Security
- AES 128 Bits Encryption Ensures Total Data Security
Networking Protocols
- 802.1D Ethernet Bridge
- 802.1Q VLAN
- Quality of Service (QoS)
AC Power
- 100-240 VAC 50Hz/60Hz
DC Power
-
- 12VDC/30W Under 86°F (30°C)
- 12VDC/24W Under 104°F (40°C)
- DC Plug: 0.25cm ID x 1.55cm OD (2.5mm ID x 5.5mm OD)
Environment Condition
- Operating temperature: 32°F ~ 104°F (0°C ~ 40°C)
- Relative humidity: 8 ~ 95% (non-condensing)
Dimensions
- 1.54in (H) x 2.83in (W) x 5.20in (D)
- 39mm (H) x 72mm (W) x 132mm (D)
Certifications
- FCC
- UL
- cUL
- CE
- ITU-T G.hn Standard
Note: Specifications are subject to change without notice.
