Features
- WiFi Everywhere You Want it: High-Performance AC1200 WiFi, together with beamforming technology, effortlessly reaches remote locations of the home.
- Seamless WiFi Mesh System: WifiXtend2.0 utilizes mesh-enhanced technologies including Adaptive Roaming and Self Healing to provide an enhanced subscriber experience.
- Remote Management for Reduced Truck Rolls: TR-069 support allows you to remotely setup, manage, troubleshoot, and control the WAP-5903
Resources
Product Sheet
Description
Two page data sheet with product pictures and specifications.
User Guide
Description
Quick Install Guide.
User Manual
Description
Complete information related to the installation and operation of this product.
Description
Download firmware updates for this product.
Specifications
Hardware
- RJ-45 X 1 for LAN (10/100/1000)
- RJ-45 X 1 for LAN/WAN (10/100/1000)
- Reset button X 1
- Dual Band WiFi Antenna X 2
WLAN
- AC1200 PHY Rate
- 5GHz: Up to 867Mbps
- 2GHz: Up to 300Mbps
- Up to 200mW TX Power
- Wireless Security WPA2-PSK
- Wireless Roaming IEEE802.11v/r
Power
- Input:100-240V—50/60Hz, 0.6A
- Output: DC 12V==1.5A
Management
- TR-069 Support
- Comtrend ACS 3.0 Cloud Management
Advanced Features
- Operation Mode: AP/Repeater
- Mesh System: WifiXtend2.0
- MU-MIMO
- Band Steering
Environment Condition
- Operating temperature: 0 ~ 40 degrees Celsius
- Relative humidity: 8 ~ 95% (non-condensing)
- Designed for indoor use only
Dimensions
- 6.49in (H) x 4.13in (W) x 3.93in (D)
- 165mm (H) x 105mm (W) x 100mm (D)
Certifications
- FCC, CE
Note: Specifications are subject to change without notice.
