Features
- Bring Your Own Wireless: Wired-only for simplified installations and reduced post-installation support calls.
- Reduce Truck Rolls: TR-069 support for remote management to easily fix issues.
- Bring High Performance Speeds in a Compact Design: Single-Port Gigabit Ethernet LAN.
Resources
Product Sheet
Description
Two page data sheet with product pictures and specifications.
Specifications
Hardware
- RJ-11 X 1 for 35b VDSL single line
- RJ-45 X 1 LAN (10/100/1000 Base-T auto-sense)
- Reset button X 1
- Power switch X 1
VDSL Features
- Supports VDSL profiles, 8a/b/c/d, 12a/b, 17a, 30a and 35b
- Supports VDSL band plan, Annex A, 997, 998
- Seamless Rate Adaption (SRA)
- G.INP support
- G.Vector support
ADSL Features
- T1.413, G.992.1 (G.dmt), G.992.2 (G.lite), G.992.3 (ADSL2) and G.992.5 (ADSL2+)
- Annexes A, L (Reach Extended ADSL2), and M (Enhanced Upstream Speed)
- Seamless Rate Adaption (SRA)
- Supports VC-based and LLC-based multiplexing
- Supports up to 8 PVCs
- ATM shaping: UBR/CBR/VBR-rt//VBR-nrt
- G.INP support
LAN
- 10/100/1000 Base T, IEEE 802.3, IEEE 802.3u IEEE 802.3ab
- Supports MDI/MDIX
Management
- TR-069/TR-098/TR-111, SNMP, Telnet, SSH, Web-based management, Configuration backup and restoration
- Software upgrade via HTTP
Diagnostics
- ATM F4/F5 OAM, 802.1ag, 802.3ah
- Ping, TraceRoute
- TR-143 (Network Throughput Performance Tests and Statistical Monitoring)
Networking Protocols
- RFC 2364 (PPPoA), RFC 2684 (RFC 1483) Bridge/Router, RFC 2516 (PPPoE); RFC 1577 (IPoA)
- PPPoE pass-through, Multiple PPPoE sessions on single WAN interface
- PPPoE filtering of non-PPPoE packets between WAN and LAN
- Transparent bridging between LAN and WAN interfaces
- 802.1p/802.1q VLAN, DSCP
- IGMP Proxy V1/V2/V3, IGMP Snooping V1/V2/V3, Fast leave
- Static route, RIP v1/v2, ARP, RARP, SNTP
- DHCP Server/Client/Relay, DNS Proxy/ Relay, Dynamic DNS, UPnP, DLNA
- IPv6 Dual Stack, IPV6 Rapid Deployment (6RD)
Firewall/Filtering
- Stateful Packet Inspection Firewall
- Stateless Packet Filter
- URI/URL filtering
- TCP/IP/Port/interface filtering rules support both incoming and outgoing filtering
NAT/PAT
- NAT Loopback
- Port Triggering
- Port Forwarding (Virtual Server)
- Symmetric port-overloading NAT
- VPN Pass Through (PPTP, L2TP, IPSec)
- DMZ host
Environment
- Operating temperature: 32~104°F (0~40°C)
- Operating humidity: 10~90% (non-condensing)
- Storage temperature: -40~158°F (-40~70°C)
- Storage humidity: 5~90% (non-condensing)
