Features
Key Benefits:
Integrate your PoE & Non-PoE Networks
- Reduce costs by using an existing non-PoE switch with the PoE-9211 to connect your PoE enabled devices.
Simplify Deployment of PoE Enabled Devices
- Eliminate the need to install high voltage outlets in hard-to-reach locations (i.e. ceilings, rooftops, etc.)
Enjoy Ultra-Fast Wired Connectivity
- Gigabit port—10x the speed of standard ports.
Easy Setup
- Three simple steps and your PoE enabled device is connected
Resources
Specifications
Hardware
- 1 Port RJ-45 10/100/1000Base-T Input Port
- 1 Port RJ-45 10/100/1000Base-T PoE Output Port
- Power Input: 100-240V AC, 50-60Hz, 0.6A
- Power Consumption 30 Watts
- Dimensions: 6.10 (L) x 2.28 (W) x 1.42 (H) in; 155 (L) x 58 (W) x 36 (H) mm
- Weight: 185g; 3.88oz
Power over Ethernet
- Standard: IEEE 802.3af, IEEE 802.3at
- Power Output: DC53V/0.55A
- Pin Assignment: 1/2 (+), 3/6 (-) End-Span
Environment
- Temperature: 32°F-104°F; 0°C-40°C (RH Non-Condensing)
- Storage Temperature: 5%~90% (Non-Condensing)
Standards Compliance
- Standards:
- IEEE 802.3 10BaseT Ethernet
- IEEE 802.3u 100BaseTX Fast Ethernet
- IEEE 802.3ab 1000BaseT Gigabit Ethernet
- IEEE 802.3af Power Over Ethernet (PoE)
- IEEE 802.3at Power over Ethernet Plus (PoE+)
Certifications
- FCC, CE, Class A
